Eureka E85 - CLEANING THE SUCTION FILTER; CHECKING THE COVER SEAL

33
CLEANING THE SUCTION FILTER
The machine is fitted with a stainless steel washable cartridge filter or – as optional – with a PU filter on the suction duct,
which provides two functions:
1) To filter the air vacuumed by the squeegee, trapping dust before releasing it into the environment, without putting it
back into the air;
2) To protect the suction motor against dust that may ruin moving mechanical parts, making them last longer.
Follow the instructions below to clean the filter:
 Bring the machine into a stop position in a flat
surface area and put on the brake
 Turn off the machine and remove
the key.
 Open the cover (see position 2);
 Unscrew the locking filter handwheel pos.1;
 Remove the filter pos.3 from its seat;
 Wash the filter with water and dry it using hot air,
be careful not to damage it;
 Put the air filter back into place (see position 3);
 Lower the locking filter handwheel pos.1;
 Close the tank cover pos.2.
CHECK THE SEAL ON THE COVER
The recovery tank cover seal ensures that a proper
vacuum is created inside the tank and this provides
a better suction performance on the squeegee.
It is very important to keep the seal intact in order
for the machine to work properly.
To clean and check the seal, proceed as follows:
 Open the cover (see position 1);
 Use a piece of cloth to wipe off the seal (see
position 32 and make sure it is not broken or
damaged;
 If the seal is damaged, remove it from the cover,
mount a new seal and make sure to fit the seam
of the seal into the rear position (see position 3);
 Clean the area of the tank where the seal leans
(see position 4) when the cover is closed.
