OPERATIONS TO BE CARRIED OUT ONCE EVERY 500
WORKING HOURS AS TO CHECK THE OIL LEVEL OF
THE DRIVE WHEEL REDUCER:
1. Check the oil level by removing the level/oil cap (Pos.1)
2. If necessary, fill up the wheel reducer with SYNTHETIC OR
MINERAL OIL SAE 80W90 up to the level and then refit
the cap (Pos.1).
OPERATIONS TO BE CARRIED OUT ONCE EVERY 2000
WORKING HOURS AS TO REPLACE THE OIL OF THE
DRIVE WHEEL REDUCER
1) Unscrew and remove the level/oil filling cap (Pos.1) ;
2) Fit a suitable baisin for the oil gathering. Then, unscrew the
drain plug Pos 2 and remove it as to wait for the oil outflow;
3) Remove any metallic waste which got stuck on the drain plug
4) Refit the drain plug Pos.2 by means of a proper gasket;
Fill up the reducer with SYNTHETIC OR MINERAL OIL SAE
80W90 up to the level and then refit the oil filling cap (Pos.1).
