Jumpers and connectors
Issue G 33
J1 - 3.5mm audio jack
PC99 Colour: lime
Pin Connector: 2.0 mode
Connector: 5.1 mode
Tip Line out left Surround out left
Ring Line out right Surround out right
Sleeve Ground Ground
J2 - 3.5mm audio jack
PC99 Colour: light blue
Pin Connector: 2.0 mode
Connector: 5.1 mode
Tip Line in left Rear surround left
Ring Line in right Rear surround right
Sleeve Ground Ground
J3 - 3.5mm audio jack
PC99 Colour: pink
Pin Connector: 2.0 mode
Connector: 5.1 mode
Tip Microphone In Surround centre
Ring No connect Low frequency effects
Sleeve Ground Ground
