Eurotech Apollo - Page 43

Jumpers and connectors
Issue G 43
Pin Signal name Pin Signal name
29 Ground 30 DVOBCLK#
31 USB overcurrent 32 DVOBCLK
33 DVO_REF 34 DVOBHSYNC
35 /RESET 36 DVOBVSYNC
37 Ground 38 DVOBBLANK#
39 ADDID7 40 DVOBFLDSTL
41 ADDID6 42 Ground
43 ADDID5 44 DVOCD11
45 ADDID4 46 DVOCD10
47 ADDID3 48 DVOCD9
49 ADDID2 50 DVOCD8
51 ADDID1 52 DVOCD7
53 ADDID0 54 DVOCD6
55 DVODETECT 56 DVOCD5
57 DVOCFLDSTL 58 DVOCD4
59 DVOBCINTR# 60 DVOCD3
61 DVOBCCLKINT 62 DVOCD2
63 Ground 64 DVOCD1
65 +1.5V 66 DVOCD0
67 +1.5V 68 Ground
69 +1.5V 70 DVOCCLK#
71 +1.5V 72 DVOCCLK
73 MI2CDATA 74 DVOCHSYNC
75 MI2CCLK 76 DVOCVSYNC
77 MDVIDATA 78 DVOCBLANK#
79 MDVICLK 80 Ground
