EVCO S.p.A. c-pro 3 | Hardware manual ver. 2.0 | Code 114CP3E204
page 20 of 86
PROG
Programming and debugging port.
POWER SUPPLY
Power supply.
Terminal Meaning
V≅
power supply controller (24 VAC / 20... 40 VDC)
V≅
power supply controller (24 VAC / 20... 40 VDC)
The maximum length of the connecting cables of the power supply of the controller is 30 m (98 ft).
Protect the power supply with a fuse rated 0.8A-T 250 V.
If the controller is powered in direct current, one will not have to respect the polarity of the power supply voltage.
