Deep Well Installation
For wells between 25 ft. and 110 ft. in depth, deep well installations should be adapted.
The deep well installations have one 1-1/4 in. pipe and one 1 in. pipe between the pump and ejector.
MATERIALS REQUIRED (NOT INCLUDED)
Part Additional items needed Quantity
AA 1-1/4 in. Foot Valve 1
BB 1-1/4 in. Priming Tee 1
CC 1 in. Female PVC Adaptor 4
DD 1/2 in. Pressure Relief Valve 1
EE 1-1/4 in. PVC Pipe Schedule 80, or PVC Pipe Schedule 40 as needed
FF 1-1/4 in. Coupling (required if using PVC Pipe) 1
GG 1/2 in. x 1/2 in. Drain Valve 1
HH 4 in. Well Seal 1
II 1-1/4 in. Flexible PVC Coupling (required if using PVC Pipe) 1
LL 1 in. Male Adaptor 1
MM 10 in. Tank Tee (or recommended size based on tank size) 1
NN 1/4 in. Plug 1
OO 2 in. Pressure Gauge 0-100 Psi 1
PP 1-1/4 in. Male Adaptor 4
QQ 1 in. PVC Pipe Schedule 80, or PVC Pipe Schedule as needed
RR 1 in. PVC Elbow 1
SS 1 in. PVC Coupling as needed
TT 1 in. x 3 in. Nipple 1
UU 1-1/4 in. x 4 in. Galvanized Steel Nipple 1
VV 1 in. Flexible PVC Coupling (required if using PVC Pipe) 1
WW 1 in. Pressure Regulator 1
YY 3/4 in. MNPT x 1 in. slip PVC adapter 1
NOTE: Either Schedule 40 or 80 pipe will work in this installation.
Be sure to check your state and local building codes.
REPLACING AN EXISTING PUMP
WARNING: RISK OF ELECTRIC SHOCK
Can shock, burn or kill. Disconnect power to pump before working on
pump or motor.
Drain and remove the old pump and the ejector from the well. Check pipe for scale, lime, rust, etc., and replace it if necessary.
NOTE: Your old ejector (in the well) can’t be properly matched to your
new pump. You must use the included ejector with your new pump.
