4
Pre-Installation
APPLICATION
This unit is a convertible jet pump designed for pumping water where the water level is less than 110 ft. deep. If the water level to the
pump is deeper than 110 ft. a deep well submersible pump should be selected. A pressure switch pre-set at 30 Psi "on"/ 50 Psi "off" has
been installed on the pump. The pressure switch will automatically turn the pump on and off based on the system pressure.
TOOLS REQUIRED
Flathead
Screwdriver
Phillips
Screwdriver
Wrench
PVC
PVC
Cement
PVC
PVC
Primer
Safety
goggles
Tape
Measure
Thread
Tape
Tyre
pressure
gauge
Pipe
Clamp
PACKAGE CONTENTS
B C E
Part Description Quantity
A Pump 1
B
Short venturi tube (for shallow well installation)
1
C 1
A D
D Long venturi tube (for deep well installation) 1
E Pressure gauge 1
Ejector Kit
