RS232
○
8
RS232 connector
9-pin Sub-D control input/output for service purpose.
RS485
○
9
RS485 connector
RJ 45 Connector to cascade multi Digital Video Recorder.
VGA
○
10
VGA
Connect to the monitor that has VGA input.
Remote Control (extension cable is optional)
○
11
Remote Control
Connector to connect IR extension cable that has an IR remote control receiver.
SCSI (Only available for EDVR16D3)
○
12
SCSI Connector
For connecting the optional extension unit.
S-Video (Only available for EDVR16D3)
○
13
S-Video
Provides S-Video connector.
