NORMAL
IPS recording rate for manual or scheduled recording and recording controlled through
“REC IN” input contact. The maximum image rate is limited to:
Max. image rate per camera = max. DVR recording rate / number of installed cameras.
Max. DVR recording rate depends on recording resolution:
Model Resolution
N/P
IPS
N/P
360 x 240 / 360 x 288 120/100
720 x 240 / 720 x 288 60/50
D1/F1
720 x 480 / 720 x 576 30/25
360 x 240 / 360 x 288 240/200
720 x 240 / 720 x 288 120/100
D2/F2
720 x 480 / 720 x 576 60/50
360 x 240 / 360 x 288 480/400
720 x 240 / 720 x 288 240/200
D3
720 x 480 / 720 x 576 120/100
Example:
EDVR9F1/D1 with 12 installed cameras, resolution 720 x 240: 60 IPS / 12 = 5 IPS,
therefore the maximum adjustable recording rate per camera is 5 IPS.
EVENT
Event record speed (Images per second) up to 30/25 IPS or “OFF”.
Note: In order to validate a new record speed, you need to disable all record actions
before setting up.
SET
Set “ON” when using schedule recording.
Set “OFF” when not using schedule recording.
Note: The status of SET can only be changed in the SCHEDULE SETUP MENU.
25
