10. ALARM NETWORK
YES: Enable alarm network.
NO: Disable alarm network.
11. MAIN MON: Display on a main monitor when an alarm occurs.
NO CHANGE: No change on the display in the main monitor when an alarm occurs.
FULLSCREEN: A full screen of the active camera will display when an alarm occurs.
12. CALL MON: Display on a call monitor when an alarm occurs.
NO CHANGE: No change on the display in call monitor when an alarm occurs.
SEQUENCE: Display in sequence mode on call monitor when an alarm occurs,
according to sequence retention period set in Camera Setup Menu.
ACTIVE CAMERA: Display the active camera in full screen mode to the call
monitor.
13. SUMMARY
Dial Jog to change items in the SUMMARY table. All alarm’s statuses are shown in
SUMMARY tables. These tables are for checking alarm overall statuses, but not for
setting.
Note: Please check APPENDIX B to see other available alarm input / output functions.
31
