DVR provides a record function which is triggered by external signal via the 19th pin of the
ALARM INPUT / OUTPUT port. When the record input signal is pulled low constantly, DVR
will start to record. The system will stop recording when the record input signal is not pulled
low.
Note: Please check APPENDIX B to see other available alarm input/output details.
