61
SPECIFICATIONS
75, 90 Models
Displacement 79.1 cu. in. (1296 cc)
Engine Type In-line, 3 Cylinder, Two-Cycle, E-TEC
Full Throttle Operating
Range
75 HP – 4500 to 5500 RPM
90 HP – 4500 to 5500 RPM
Power
(1)
(1) Rated following the standards of ICOMIA 28.83, ISO 3046 and NMMA.
75 HP – 75 HP (56 kw) @ 5000 RPM
90 HP – 90 HP (67.1 kw) @ 5000 RPM
Idle RPM in Gear
(2)
(2) Emission Control Information.
700 ± 50
Idle RPM in Neutral
(2)
600 ± 50
Ignition Timing
(2)
Not Adjustable
Emission Control System:
per SAE J1930
(2)
ECM, E-TEC (Engine Control Module, E-TEC)
Fuel Requirements
(2)
87 Pump Posted AKI (90 RON)
– Refer to Fuel Requirements on page 18
Oil – Lubricant
– Capacity
TC-W3 NMMA-certified oil or Evinrude/Johnson XD100 oil
– Refer to Oil Requirements on page 16
3.0 qt. (2.8 l)
Warning Signals Controlled by the outboard’s EMM
Battery, Minimum
(3)
(3) Use a 800 CCA (1000 MCA) battery when operating in temperatures below 32°F (0°C).
640 CCA (800 MCA) 12 volt or
800 CCA (1000 MCA) 12 volt below 32°F (0°C)
Spark Plug
(2)
Refer to ECI Label
Fuses Refer to Fuse on page 47
Fuel Filter P/N 967545 – In-line Replaceable
Battery Charging 25-Amp, Fully Regulated
Gearcase – Lubricant
(4)
– Capacity
(4) Use Evinrude/Johnson HPF Pro Gearcase Lubricant for high performance outboards and commercial
applications. Evinrude/Johnson HPF Pro Gearcase Lubricant delivers exceptional durability and reliability
and promotes long gearcase life in marine use.
Evinrude Ultra-HPF
L Models – 31.6 fl. oz. (935 ml)
X Models – 32.8 fl. oz. (970 ml)
Power Trim/Tilt – Fluid
Capacity
21 fl. oz. (622 ml)
Propeller Refer to Propeller Selection on page 58
Weight L Models – 320 lbs. (145 kg)
X Models – 335 lbs. (152 kg)
Sound at Driver’s Ear
(LpA) ICOMIA 39.94
76.8 dB(A)
Transom Height L Models – 19 1/2 to 20 in. (495 to 508 mm)
X Models – 24 1/2 to 25 in. (622 to 635 mm)
