EXERCISE CAUTION WHEN INSTALLING
THE BATTERY, AS THERE IS A
POTENTIAL PINCH POINT BETWEEN
THE UNDERSIDE OF THE SADDLE,
SADDLE RAILS AND BATTERY.
WARNING
/37
INSTALL BATTERY
To install your battery into the Saddle, ensure the battery is turned off.
1. Ensure the battery is off and check there is no obstacle inside the Saddle.
Shift the Drive System Cable to the side.
2. Push the battery into 3/4 of the way into the Saddle and hold in place.
3. Plug the Drive System cable into the Battery.
4. Continue to push the battery home. Ensure the Battery is assembled
properly with the Lock Button engaged with the Cross Bar of the Saddle.
1
2
4
3
