HANDLEBARS
1
2
3
1 2 3
/20
1. Using a 6MM Allen key, loosen the 2 Stem Bolts (1) from the sides of the
handlebar Stem. Rotate the Stem and forks (2) to face the front of the
bike (3).
2. Ensure the Stem is facing the front of the bike (1) and is parallel to the
frame (2). Once con dent in the alignment, tighten the 2 Stem bolts on
either side of the Stem (3).
FINAL ADJUSTMENT OF THESE BOLTS OCCURS DURING
ADJUSTMENT AND TORQUING PG. 27.
