7. Drawings V10k automatic
50
EN
Anti‐syphon‐Injector 3/4" with accessory
Pos Part no. Description Qty.
1 W3T171370 Injector 3/4" PVC-U 1
2 Nozzle 1
3 Tailway 1
4 W3T167396 Adaptor union incl. o-ring DN25-R 3/4"
d32.92 x 3.52
1
W3T163750 Adaptor union incl. o-ring DN 20-R 3/4
d28.17 x 3.52
1
5 W3T163705 Adaptor union incl. o-ring DN25-R 3/4"
d32.92 x 3.52
1
7 W2T505599 Reduction d32+40-20+25 1
W2T507634 Socket PVC-U;d32 1
W2T505442 Reduction d32+40-25+32 1
W2T505599 Reduction d32+40-20+25 1
10 W3T167194 Adaptor nipple PVC, 1/2"NPT x DN 15 1
11 W3T171372 Connector for hose 3/8 x 1/2" 1
W3T161698 Connector 1/2-14NPT 1
W3T171353 Connector for hose D3/8" d1/4" 1
12 W3T172724 O-ring d20,22 x 3,53/FPM 1
13 W2T507291 Union end PVC-U; d20 1
14 W2T506920 Union end PVC-U; d20 1
15 W3T169068 O-ring d13,94 x 2,62/FPM 1
16 W3T169073 O-ring d21,89 x 2,62/FPM 1
20 W3T163692 Console 1
