Ewellix THG - Ordering Key

39
11.0 Appendix
Safety factor load conditions
Designation Order number
Top mounting plate for 2× tube set SPL-264265 0125688
Bottom mounting plate for 2× tube set SMT-264363 0124814
Top mounting plate for 3× tube set SPL-264265 0125688
Bottom mounting plate for 3× tube set SPL-264237 0125623
Screw (4/plate) for mounting plate ZBE-510707 0125622
Plug AC Telemag 3 pin ZBE-510707 0125360
Accessories
Type
Voltage
24 V DC 0
24VDCwithintegratedcurrentcut-o 1
Load
2 000 N B
1 000 N C
Tube set
Tube set 2× A
Tube set 3× D
Stroke (S)
200 mm 2
300 mm 3
400 mm 4
500 mm 5
600 mm 6
700 mm 7
Cable / connecting plug
Straight, 1,0 m / jack plug 1
Straight, 2,3 m / jack plug 2
Coiled, 0,6 m / jack plug A
Straight, 1,0 m / DIN8 plug 3
Straight, 2,3 m / DIN8 plug 4
Coiled, 0,6 m / DIN8 plug B
Option
No option 0 0
1-Hall encoder, 8 pulses, cable with jack plug A
Potentiometer, 1 k, 2 Watt, 0,25 % linearity, 10 turns (tube set 3 × only) B
Cable feedthrough, 5 × 0,75 mm2, top +160 mm, bottom +800 mm C
Cable feedthrough, 1-Hall encoder, 8 pulses, cable with jack plug D
Cable feedthrough, potentiometer (tube set 3 × only) E
2-Hall encoder, cable with DIN8 plug F
Cable feedthrough, 2-Hall encoder, cable with DIN8 plug G
Ordering key
Options shown in yellow are only available on request. Contact Ewellix for more information on minimum quantities and additional costs.
T H G
1
– – 0 0 0
