Ewellix THG - Ordering Key

43
11.0 Appendix
Accessories
Designation Order number
Top mounting plate for 2 × tube set ZPL-290268 0125624
Bottom mounting plate for 2 × tube set ZPL-290351 0125625
Top mounting plate for 3 × tube set ZPL-290268 0125624
Bottom mounting plate for 3 v tube set ZPL-290265 0125623
Screw (4/plate) for mounting plate ZBE-510707 0125360
Options written in yellow are only available on demand. Contact Ewellix for more information on minimum quantities and additional costs.
Ordering key
Type
Voltage
24 V DC 0
24VDCwithintegratedcurrentcut-o(onlyfor4000Nand1500Nloadversion) 1
Load
4 000 N A
2 500 N B
1 500 N C
Tube set
Tube set 2× A
Tube set 3× D
Stroke [S]
200 mm 2
300 mm 3
400 mm 4
500 mm 5
600 mm 6
700 mm 7
Cable / connecting plug
Straight, 1,0 m / jack plug 1
Straight, 2,3 m / jack plug 2
Coiled, 0,6 m / jack plug A
Straight, 1,0 m / DIN8 plug 3
Straight, 2,3 m / DIN8 plug 4
Coiled, 0,6 m / DIN8 plug B
Option
No option 0
1-Hall encoder, 8 pulses, cable with jack plug A
Potentiometer,1kΩ,2Watt,0,25%linearity,10turns B
Cable feedthrough, 5 × 0,75 mm2, led out, top +160 mm, bottom +800 mm C
Cable feedthrough, 1-Hall encoder, 8 pulses, cable with jack plug D
Cable feedthrough, potentiometer E
2-Hall encoder, cable with DIN8 plug F
Cable feedthrough, 2-Hall encoder, cable with DIN8 plug G
T L G
1
– – 0 0 0
