Design and function
MMA welding
70
099-004854-EW501
19.02.2014
Item
Symbol
Description 0
1
Connection socket, welding current “-” (with DC- polarity)
connection for Electrode holder
2
Connection socket, welding current “+” (with DC- polarity)
Connection for workpiece lead
• Insert cable plug of the electrode holder into either the "+" or "-" welding current connection socket and
lock by turning to the right.
• Insert cable plug of the workpiece lead into either the "+" or "-" welding current connection socket and
lock by turning to the right.
NOTE
Polarity depends on the instructions from the electrode manufacturer given on the
electrode packaging.
