Technical data
WEGA 501, 601
16 Item No.: 099-004934-EWM01
3.2 WEGA 501, 601
WEGA series 501DW 601DW
Switching steps
36 (3x12)
Welding current setting range
50 - 500 A 50 - 600A
Duty cycle at 40C ambient temperature
45% DC
500 A 600 A
60% DC
435 A 520 A
100% DC
335 A 400 A
Duty cycle at 20C ambient temperature
52,5% DC
500 A 600 A
70% DC
435 A 520 A
100% DC
365 A 440 A
Open circuit voltage
16,5 - 49,5 V 16,5 - 57,5 V
Mains voltage (tolerances)
3 x 400V (+/- 15%)
Frequency
50/60Hz
Mains fuse
(safety fuse, slow-blow)
3x32A
Max. connected power
27,5 kVA 36,7 kVA
Workpiece lead
95 mm
2
95 mm
2
Recommended generator
power
32 kVa 50 kVA
Cosϕ
0,95
Weight
200 kg 228 kg
Dimensions (L/W/H in mm)
960 x560 x 1010
Insulation class/protection
classification
H/IP 23
Ambient temperature
-20°C to +40°C
Machine/torch cooling
Fan/water
Constructed to standards
IEC 60974-1, -5, -10 /
/
Internal cooling unit data
Max. tank capacity
9 l
Flow rate (max.)
5l/min
Initial pressure (max.)
3.5bar
