Machine description
WEGA 351, 401, 451, 501, 601 D
Item No.: 099-004934-EWM01 23
Item Symbol Description 0
1
Wire feed unit
2
Lifting lug
3 Carrying handle
4
Main switch, machine on/off
5
Step switch, welding voltage "coarse"
6
Step switch, welding voltage
7
Connection socket, workpiece lead
"Hard" choke tapping
8
Connection socket, workpiece lead
"Medium" choke tapping
9
Connection socket, workpiece lead
Choke tapping "soft"
10 Conveyor rolls, fixed castors
11 Conveyor rolls, guide castors
12 Cooling air inlet
13
Signal light, Functional error
On when excess temperature detected
14
Key button, automatic cut-out of coolant pump
Press to reset a triggered fuse
15
Coolant tank cap
16 Coolant tank
NOTE
Step switch, "coarse" welding voltage not applicable with WEGA 351
Coolant tank only for machines fitted with water cooling (DW)
