29 FPM-600/FLS-600
Measuring Power or Loss (FPM-600)
Activating Hold Min/Max Power Mode
Activating Hold Min/Max Power Mode
With the Hold Min/Max mode you can record
extreme values of a varying power signal. You
could use it to test the stability of a light source
over time.
In this mode, the unit displays the minimum or maximum power
value read up to now. It continuously updates the display if a new
min/max is measured.
To activate the Hold Min or Hold Max mode:
Press to switch between Hold Max, Hold Min and regular power
measurement.
To reset the maximum or minimum value:
Hold down for a few seconds. The unit displays “_ _ _ _”.
