Operating the Optical Switch
Optical Switch 31
Installing the RTUe-9110/RTUe-9120 External Switch in a Rack
6b. Fix the first adapter on the switch’s mounting bracket with the
supplied screw, flat washer and nut as shown below.
6c. Repeat steps 6a and 6b with the other adapter, ensuring that you
place the adapter at the exact same position (orientation of the
adapter, hole on the adapter).
7. Place the switch in the rack at the desired height.
