Multimeter Tests
MaxTester Copper Test 95
Voltage
To select the parameter values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options.
4. Press to confirm the value.
Voltage Thresholds
The AC/DC Voltage Threshold Settings page allows
you to set the Threshold Voltage for each pair.
 Type is the threshold limit for each pair: either
Maximum or Minimum.
 Enabled is a flag to use the voltage threshold:
either Yes or No.
To set threshold values:
1. Press the up/down arrow keys to highlight the
desired parameter.
2. Press the left/right arrow keys to view and select
the options.
OR
3. Press on a value to open a list box of options or the alphanumeric
editor screen and use the navigation keys to scroll through.
4. Press to confirm the value.
