Noise Tests
MaxTester Copper Test 147
Power Influence
Power Influence Threshold Settings
The Threshold Settings page allows you to set the
Threshold Power Influence values for the test.
Type is the threshold limit: either Maximum or
Minimum.
Enabled is a flag to use the current threshold:
either Yes or No.
To set threshold values:
1. Press the up/down arrow keys to highlight the
desired parameter.
2. Press the left/right arrow keys to view and select
the options.
OR
3. Press on a value to open a list box of options or the alphanumeric
editor screen and use the navigation keys to scroll through.
4. Press to confirm the value.
Result Details
The Result Details read-only page displays the Power
Influence value and graph, and the pass/fail status.
