Noise Tests
MaxTester Copper Test 159
WB Impulse Noise
WB Impulse Noise Threshold Settings
The Threshold Settings page allows you to set the
WB Impulse Noise Threshold values for the test.
 Power Detection Level defines the threshold
limits.
 Counter allows you to set the threshold value for
this counter.
 Type is the threshold limit for each pair: either
Maximum or Minimum.
 Enabled is a flag to use the current threshold:
either Yes or No.
To set threshold values:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options or the alphanumeric
editor screen and use the navigation keys to scroll through.
4. Press to confirm the value.
