Noise Tests
168 MAX-610
NEXT
Threshold Settings button opens a new page that allows you to set the
NEXT Spectrum Threshold.
Select Graph button changes to Graph Selected when pressed and
opens a new selection of function keys which allow you to maneuver
the graph as follows:
Cursor - press the left/right arrow keys to decrease/increase the
values by moving the cursor. Press and hold the left/right arrow
keys to accelerate the cursor. Press to recall the cursor and
place it in the middle of the current x-axis limits.
Zoom references the middle of the x/y axis and not the cursor
position. Press the arrow keys as follows:
Right = x-axis zoom in.
Left = x-axis zoom out.
Up = y-axis zoom in.
Down = y-axis zoom out.
Pan - use left/right arrow keys to pan the x-axis and the up/down
arrow keys to pan the y-axis.
1:1 resets the x-axis and y-axis limits to full scale.
Return To Test removes these function keys and displays the
Spectrum page.
Result displays the pass/fail status, and test results in graphical format.
Good is the good threshold value for the selected bandwidth,
represented by a horizontal green line.
Test Status displays the current state of measurement or an error
message.
