Frequency Tests
MaxTester Copper Test 183
WB Balance
To select the parameter values in Portrait or Landscape modes:
1. Press the up/down arrow keys to highlight the desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options.
4. Press to confirm the value.
WB Balance Threshold Settings
The Threshold Settings page allows you to set the
Good/Marginal Balance thresholds for: ADSL2+,
VDSL2-8, VDSL2-12, or VDSL2-17.
 Type is the threshold limit: either Maximum or
Minimum.
 Enabled is a flag to use the current threshold:
either Yes or No.
To set threshold values:
1. Press the up/down arrow keys to highlight the
desired parameter.
2. Press the left/right arrow keys to view and select the options.
OR
3. Press on a value to open a list box of options or the alphanumeric
editor screen and use the navigation keys to scroll through.
4. Press to confirm the value.
