Programming Menu
7
7.3 Recording Menu
In the Recording menu you can start/stop the data logger, configure the log-
ging sample rate (gap) and session duration (time), and view/erase logged
data. Use the arrow buttons to scroll. Press F3
✔ to open or select an option.
See Section 8, Data Logging, for specifics.
Figure 7.4 The first Recording menu page. See Section 8, Data Recording, for additional
display pages and instructions.
7.4 Environment Menu
In the Environment menu you can set the probe’s pressure and molar mass
values to match the gas pressure/molar mass under test. In this menu, you
can also purge the probe of process liquids and condensation by selecting
Purification. Use the arrow buttons to scroll. Press F3
✔ to open or select an
option. See Section 4 for specifics on Probe Pressure, Molar Mass, and
Purification.
Figure 7.5 The first Environment menu page. See dedicated Probe section for additional
screens and instructions.
#NAS100113; r. AA/87024/87024; en-US
14
