AvediaStream e2535/e3635 and e2655/e3655 Encoders V1.1
16 Administrator’s Guide
SDI Interface (OUT)
The SDI (OUT) interface is a loop-through interface to enable you to connect the same SDI
input to another device.
Connect using a BNC connector.
This output is disabled by default, and can be configured via the web interface Input page.
Caution: Do not connect the output interface to any other output interface as this may damage
the unit.
Audio Inputs
● Embedded SDI stereo audio (stereo pair selectable from one of 8 pairs embedded within
the SDI video stream)
● S/PDIF digital audio (RCA phono) (PCM 48kHz)
This allows you to encode audio from the SDI interface or to use the AES interface as the
audio source
Note: Only 48kHz PCM audio is supported by the encoder. Other detected sample rates result
in “unsupported sampling rate” being displayed on the Status page.
