AvediaStream e2535/e3635 and e2655/e3655 Encoders V1.1
20 Administrator’s Guide
The AvediaServer Director can perform the following actions:
● Name - specify the Encoder name
● Location – specify the Encoder location
● Reboot – re-start the Encoder
● Ping – Ping the Encoder
● Upgrade Firmware – Upload new device firmware
● Factory Reset – set the Encoder back to factory default configuration
● Export Config – export the current configuration for archiving or applying to another
device
● Import Config – restore the Encoder to a previously saved configuration
● Set TFTP Server – specify the IP address of the TFTP server to be used
● Set Syslog Server – specify the IP address of the Syslog server to be used
To start the encoder web interface with AvediaServer Director:
1. Open the AvediaServer web interface and start the Director application. Click the
AvediaStream tab to list all streaming devices in the IPTV system.
2. Select Encoder from the Device drop down list to display only encoders.
3. Use the column sort functions to help locate the encoder you want to configure.
4. Click the required encoder name hyperlink to launch the web interface login window as
shown in Figure 4.
5. Enter the admin login credentials to display the Encoder web interface as shown in Figure
5.
To open the admin interface via telnet with AvediaServer Director:
1. Open the AvediaServer web interface and start the Director application. Click the
AvediaStream tab to list all streaming devices in the IPTV system.
2. Select Encoder from the Device drop down list to display only encoders.
3. Use the column sort functions to help locate the encoder you want to configure.
4. Click the required encoder icon hyperlink in the Name column to launch the admin
interface window as shown in Figure 7.
