AvediaStream e2635/e3635 and e2655/e3655 Encoders V1.1
Administrator’s Guide 41
Test Pattern
You can configure the AvediaStream e2635/55 and e3635/55 encoders to output a selection of
test patterns continuously, or only when no input signal is detected. Test patterns can be
useful during system commissioning when no other content is available, or to highlight the lack
of an input signal.
A selection of preset colours can be applied to the solid colour test pattern, or if required, you
can specify your own custom colour value in RGB format (#000000 to #FFFFFF).
Figure 19 Test Pattern - Solid Custom Colour
Figure 20 AvediaPlayer Desktop - Bars 75% Test Pattern
