IN1606 and IN1608 Series Scaling Presentation Switcher • SIS Configuration and Control 51
Command ASCII Command
(host to scaler)
Response
(scaler to host)
Additional Description
Pixel phase (available only for RGB and YUV-HD input signals)
Specify a value
EX%PHAS} PhasX!*X%] Set the pixel phase to X% on the current input.
Increment value
E+PHAS} PhasX!*X%]
Increase the pixel phase by one on the current
input.
Decrement value
E-PHAS} PhasX!*X%]
Decrease the pixel phase by one on the
current input.
View
EPHAS} X%]
View the pixel phase setting on the current
input.
Total pixels (available only for RGB and YUV-HD input signals)
Specify a value
EX^TPIX} Tpix X!*X^] Set the total pixels to X^ on the current input.
Increment value
E+TPIX} TpixX!*X^]
Increase the total pixels by one on the current
input.
Decrement value
E-TPIX} TpixX!*X^]
Decrease the total pixels by one on the
current input.
View
ETPIX} X^]
View the total pixel setting on the current
input.
Active pixels
Specify a value
EX&APIX} ApixX!*X&] Set the active pixels to X& on the current
input.
Increment value
E+APIX} ApixX!*X&]
Increase the active pixels by one on the
current input.
Decrement value
E-APIX} ApixX!*X&]
Decrease the active pixels by one on the
current input.
View
EAPIX} X&]
View the active pixel setting on the current
input.
Active lines
Specify a value
EX*ALIN} Alin X!*X*] Set the active lines to X* on the current input.
Increment value
E+ALIN} AlinX!*X*]
Increase the active lines by one on the current
input.
Decrement value
E-ALIN} AlinX!*X*]
Decrease the active lines by one on the
current input.
View
EALIN} X*]
View the active lines setting on the current
input.
3:2, 2:2, 24:1 Film mode detect
Auto
EX!*1FILM} FilmX!*X1@]
Set film mode detection to automatic (default).
Off
EX!*0FILM} Film X!*X1@]
Disable film mode detection.
View setting
EX!FILM} X1@]
View the current film mode setting.
NOTES:
X! = Input selection
1-6 (IN1606) or 1-8 (IN1608 Series)
X% = Pixel phase
0-63 (31 = default)
X^ = Total pixels
±
512 of the default value
X& = Active pixels
±
512 of the default value
X* = Active lines
±
256 of the default value
X1@ = Film detect mode
0 = disabled
1 = auto (default)
