IN1606 and IN1608 Series Scaling Presentation Switcher • Configuration Software 70
Offline Device Preview
Opening a new device tab for an offline device displays the interface and confirguration
options for the chosen model without connecting to it. However, settings cannot be
changed.
To open a scaler device tab:
1. In the Start-up drop-down menu, select New Configuration File. The New
Configuration File
dialog box opens.
Figure 37. Configuration File Drop-Down Menu
NOTE: The Open Configuration File option is not available for the IN1606 or
IN1608 Series.
Figure 38. New Configuration File Dialog Box (IN1608 Selected)
2. Select the desired device model from the Device Models list (see figure 38,
1
).
3. Click the Configure button (
2
). A new offline device configuration tab opens.
