IN1606 and IN1608 Series Scaling Presentation Switcher • SIS Configuration and Control 52
Command ASCII Command
(host to scaler)
Response
(scaler to host)
Additional Description
Picture Adjustment Commands
Video mute (defaults to unmuted after a power cycle)
Mute output video
X@*1B VmtX@*1] Mute video only on output X@.
Mute output sync and video
X@*2B VmtX@*2] Mute sync and video on output X@.
Unmute output
X@*0B VmtX@*0] Umute the output X@.
View output mute status
X@*B X2*] View the mute status on output X@.
Mute video to black
1B
Vmt1
]
Mute video to black on all outputs.
Mute sync and video
2B
Vmt2
]
Mute video and sync on all outputs.
Unmute sync and video
0B
Vmt0
]
Unmute all outputs.
View mute status on all outputs
B
X5%]
View the mute status on all outputs.
Color (NTSC, PAL, and SECAM inputs only)
Specify a value
EX1%COLR} ColrX!*X1%]
Set the color level on the current input.
Increment value
E+COLR} ColrX!*X1%]
Increase the color level by one.
Decrement value
E-COLR} ColrX!*X1%]
Decrease the color level by one.
View
ECOLR} X1%]
View the color level setting.
Tint (NTSC inputs only)
Specify a value
EX1%TINT} TintX!*X1%]
Set the tint on the current input.
Increment value
E+TINT} TintX!*X1%]
Increase the tint by one.
Decrement value
E-TINT} TintX!*X1%]
Decrease the tint by one.
View
ETINT} X1%]
View the tint setting.
Contrast
Specify a value
EX1%CONT} ContX!*X1%]
Set the contrast for the current input.
Increment value
E+CONT} ContX!*X1%]
Increase the contrast by one.
Decrement value
E-CONT} ContX!*X1%]
Decrease the contrast by one.
View
ECONT} X1%]
View the contrast setting.
Brightness
Specify a value
EX1%BRIT} BritX!*X1%]
Set the brightness on the current input.
Increment value
E+BRIT} BritX!*X1%]
Increase the brightness by one.
Decrement value
E-BRIT} BritX!*X1%]
Decrease the brightness by one.
View
EBRIT} X1%]
View the brightness setting.
NOTES:
X! = Input selection
1-6 (IN1606) or 1-8 (IN1608 Series)
X@ = Output selection
1 = HDMI A (top)
2 = HDMI B (bottom)
3 = Out C
X1% = Picture adjustment
0-127 (64 = default)
X2* = Video output mute
0 = unmute
1 = mute video
2 = mute video and sync
X5% = Video mute on all outputs
0 = all outputs are unmuted
1 = at least one output is muted
2 = at least one output is muted and sync is disabled
