IN1606 and IN1608 Series Scaling Presentation Switcher • SIS Configuration and Control 53
Command ASCII Command
(host to scaler)
Response
(scaler to host)
Additional Description
Detail filter
Specify a value
EX1%HDET} HdetX!*X1%]
Set the detail filter for the current input
to X1%.
Increment value
E+HDET} HdetX!*X1%]
Increase the detail by one.
Decrement value
E-HDET} HdetX!*X1%]
Decrease the detail by one.
View
EHDET} X1%]
View the detail filter setting.
Horizontal shift (image)
Specify a value
EX1^HCTR} HctrX1^] Set the horizontal position to X1^.
Increment value
E+HCTR} HctrX1^]
Increase the horizontal position by one.
Decrement value
E-HCTR} HctrX1^]
Decrease the horizontal position by
one.
View
EHCTR} X1^]
View the horizontal position setting.
Vertical shift (image)
Specify a value
EX1&VCTR} VctrX1&] Set the vertical position to X1&.
Increment value
E+VCTR} VctrX1&]
Increase the vertical position by one.
Decrement value
E-VCTR} VctrX1&]
Decrease the vertical position by one.
View
EVCTR} X1&]
View the vertical position setting.
Horizontal size (image)
Specify a value
EX1*HSIZ} HsizX1*] Set the horizontal size to X1*.
Increment value
E+HSIZ} HsizX1*]
Increase the horizontal size by one.
Decrement value
E-HSIZ} HsizX1*]
Decrease the horizontal size by one.
View
EHSIZ} X1*]
View the horizontal size setting.
Vertical size (image)
Specify a value
EX1(VSIZ} VsizX1(] Set the vertical size to X1(.
Increment value
E+VSIZ} VsizX1(]
Increase the vertical size by one.
Decrement value
E-VSIZ} VsizX1(]
Decrease the vertical size by one.
View
EVSIZ} X1(]
View the vertical size setting.
Compound image position and size
Specify a value
EX1^*X1&*X1**X1(XIMG}
Set the horizontal and vertical positions
as well as the horizontal and vertical
sizes.
XimgX1^*X1&*X1**X1(]
View
EXIMG} X1^*X1&*X1**X1(]
View all position and size settings.
NOTES:
X! = Input selection
1-6 (IN1606) or 1-8 (IN1608 Series)
X1% = Picture adjustment
0-127 (64 = default)
X1^ = Horizontal position
±2048
X1& = Vertical position
±1200
X1* = Horizontal size
0-4096
X1( = Vertical size
0-2400
