IN1606 and IN1608 Series Scaling Presentation Switcher • SIS Configuration and Control 56
Command ASCII Command
(host to scaler)
Response
(scaler to host)
Additional Description
Volume knob assignment
Set volume knob group
E1*X5^KNOB} Knob1*X5^]
Set the front panel Volume knob
value to affect group X5^.
View volume knob group
E1KNOB} X5^]
View the volume knob group.
Group volume
Set volume
EDX4^*X4& GRPM} GrpmDX4^*X4&]
Set the volume to a value of
X4&.
Raise volume
EDX4^*X5! +GRPM} GrpmDX4^*X4&] Increase the volume by X5! dB.
Lower volume
EDX4^*X5! -GRPM} GrpmDX4^*X4&] Decrease the volume by X5! dB.
View volume level
EDX4^GRPM} X4&]
View the volume level.
Group mute
Group mute
EDX4**1GRPM} GrpmDX4**1] Mute group X4*.
Group unmute
EDX4**0GRPM} GrpmDX4**0] Unmute group X4*.
View group mute status
EDX4*GRPM} X(]
Group bass and treble
Set bass or treble level
EDX4(*X5)GRPM} GrpmDX4(*X5)]
Set the bass or treble to a value
of X5).
Raise bass or treble
EDX4(*X5! +GRPM} GrpmDX4(*X5)] Increase the volume by X5! dB.
Lower bass or treble
EDX4(*X5! -GRPM} GrpmDX4(*X5)] Decrease the volume by X5! dB.
View bass or treble level
EDX4(GRPM} X5)]
NOTES:
X( = Enabled or disabled
0 = off or disabled
1 = on or enabled
X4^ = Volume group number
1 = program volume
3 = mic volume
8 = variable volume
X4& = Group volume level
-1000 to 0, where -1000 = -100 dB or 0% volume and
0 = 0 dB or 100% volume
X4* = Mute group number
2 = program mute
4 = mic mute
7 = output mute
X4( = Bass and treble group number
5 = bass control
6 = treble control
X5) = Group bass and treble level
-240 to +120, where -240 = -24 dB and 120 = 12 dB
X5! = Increment value
dB value multiplied by ten, in 0.1 dB increments, to raise or
lower a
group fader (for example, 100 = 10 dB)
X5^ = Volume knob group number
1 = program volume (default)
3 = mic volume
8 = output volume
To Next Page
