IN1606 and IN1608 Series Scaling Presentation Switcher • SIS Configuration and Control 62
Command ASCII Command
(host to scaler)
Response
(scaler to host)
Additional Description
Information request
General Information
I
Vid
X!
•
AudX!
•
TypX#
•
StdX1)
•
BlkX2*
•
...
HrtX1#
•
VrtX1#]
Query firmware version
Q
x.xx
]
View firmware version.
Query full firmware version
*Q
x.xx.xxxx
]
View full firmware version.
Query part number
N
<part number>
]
View the part number.
View internal temperature
E20STAT} X1!]
View the temperature in
degrees Celsius.
Backup or restore configuration
NOTE: For more details, see Backup and Restore on page 77.
Save configuration to file system
E1*X4%XF} Cfg1*X4%]
Back up the current device
configuration.
Restore configuration from file
system
E0*X4%XF} Cfg0*X4%]
Restore device configuration.
Device naming
Set unit name
24
EX1$CN} Ipn
•
X1$]
Set the device name to X1$.
Set unit name to factory default
24
E
•
CN} Ipn
•
X3#]
Reset the device name to the
factory default.
View unit name
ECN} X1$]
View the device name.
NOTES:
X! = Input selection
1-6 (IN1606) or 1-8 (IN1608 Series)
X# = Input video format
1 = RGB
2 = YUV
3 = RGBcvS
4 = S-video
5 = composite
6 = HDMI
X1) = Input standard
0 = no signal detected on the current input
1 = NTSC 3.85
2 = PAL
3 = NTSC 4.43
4 = SECAM
- = not applicable (occurs when the input is active RGB,
YUV, or HDMI signals)
X1! = Internal temperature
In degrees Celsius
X1# = Horizontal and vertical frequencies
xxx.x
X1$ = Text label
Up to 63 characters
X2* = Video output mute
0 = unmute
1 = mute video
2 = mute video and sync
X3# = Default name
A combination of model name and the last 3 character pairs
of the MAC address
X4% = Config type
0 = IP config
2 = box-specific parameters
