Room Scheduling System • Room Agent Installation and Configuration 31
The Room Agent software retrieves a user code and prompts you to enter the code on
a Google Web page (see figure 31).
1111111111
22
22222222
33
33333333
Figure 31. User Code Dialog Box
NOTE: The Check Authorization Status button (
3
) is not available for selection
until after you have authenticated the device in step 9.
8.
Click on the link (
1
). Room Agent opens a separate browser to the Google Device
page.
9. Follow the steps on the Google Device page to authenticate the device. When the
Google Device page prompts for it, enter the User Code provided (
2
).
NOTE: The Product Name that you enter during Google calendar environment setup
(see step 12 on page 59) is the name that appears on the Google Device page.
When you are finished, the Check Authorization Status button in the Room Agent
User Code dialog box is enabled (
3
).
10. Click Check Authorization Status (
3
).
The Room Agent software checks the authorization status. Assuming no errors, it
reports Complete! (see figure 32).
1111111111
Figure 32. Completion Dialog Box
11. Click Done.
The Room Agent software appends the name of the Import Credential JSON File,
entered in step 5, to the end of the Google Account, entered in step 6, and displays
the new value in the Google Account field of the Panel Configuration window (see
figure 33,
1
, on the next page).
The Panel Configuration Window displays other fields appropriate for Google
Calendar configuration.
12. For the direct entry Room Name (
2
) setting:
a. Click in the field.
b. Type the desired value.
c. Type the keyboard <Tab> key to exit the field.
