FAAC 746 E R Z20 User Manual

4
5
746 E R 10 732099 - Rev.D
9
10
11
12
6
5
4
2
1
3
14
17
18
13
16
19
15
87
Translation of the original instructions
ENGLISH
3.7 COMPONENT IDENTIFICATION
COMPONENTS SUPPLIED
Gearmotor
1 Casing
2 Start-up capacitor
3 Transformer
4 Electronic board 780D with protective cover
5 Limit switch sensor
6 Pinion (Z16/Z20 Module 4) with hand guard
7 Anti-crushing clutch adjustment screw
8 Oil filler plug
9 Earth connector
10 Gearmotor body
11 Key release
12 Fastening brackets
Hardware/accessories
13 Gearmotor bracket guards
14 Cable glands to install in the board compartment
15 Casing screws with screw caps, terminal boards, cable lug for earth cable and
adhesive hazard warning sign
16 Closing and opening magnetic limit switches (magnets, spacers, mounting
hardware and screws)
COMPONENTS SUPPLIED SEPARATELY
The installation requires the following FAAC components that are
supplied separately:
17
18
Steel rack with spacers (to be screwed or welded on)
or
Nylon rack with mounting hardware - for leaves having a max weight of 400 kg
19 Foundation plate with mounting hardware
DANGER, AUTOMATIC MOVEMENT warning sign
