Panel PC.
CNC 8065
2.
·30·
(REF: 1801)
MONITOR-21 MULTITOUCH.
2.5 Voltage supply for the module.
The monitor has two power supply connections. Fagor Automation recommends using 24 V
DC (Phoenix-type connector) to power the monitor. Consult Fagor Automation before using
the 12 V DC option.
24 V DC universal power supply.
Option recommended by Fagor Automation to power the monitor. Power the monitor with
a 24 V DC ±10% 1.5 A power supply.
Power supply cable characteristics.
Use generic 12 AWG (4 mm²) to 18 AWG (1 mm²) cable.
Consumption.
Maximum consumption: 25 W.
Never connect both power systems at the same time.
