3.7 Configuring the video signal from the monitor.
The buttons to configure the monitor video signal are on the back. This keyboard is also used
for the OSD menu.
Button. Description.
Turns the monitor on and off.
Automatically adjusts the clock, phase, horizontal
position and vertical position.
Increases the brightness.
Reduces the brightness.
Activates the OSD menu.
Changes the video input source.
Power
Auto/Exit
Right
Source
Left
Menu/Sel
