PPC-19.
4 PPC-19.
Panel PC with 19 multi-touch monitor to control, operate and monitor the CNC via an ethernet
connection. The PPC-19 allows the user to operate the CNC using the touch screen or a
USB keyboard (for example, the HORIZONTAL KEYB 2.0 + TRACKHPAD). In both cases,
the user can work with the PPC in just the same way as if being in front of the CNC screen.
The PPC may be a standalone monitor or workstation (for example, with a modular central
unit) or it may be a second monitor or workstation (for example, with an integrated central
unit).
The CNC to which the PPC-19 will be connected must have the connection enabled through
the remote desktop (with RDP protocol support) as well as a functional Ethernet connection
with the correct parameters set. The FagorConnect application, which can be installed on
the Panel PC, makes it possible to simplify the configuration of the connection between a
Panel PC and the CNC.
Module. Description.
PPC-19---- Panel PC with a 19" (1280 × 1024) capacitive,
multi-touch, 24-bit color, 4:3 aspect ratio monitor
(10-point).
19"
