Panel PC.
CNC 8065
3.
·44·
(REF: 1801)
PPC-21W.
3.1 Specifications.
Type. Description.
General. • 21.5" (1920 × 1080 pixel) multi-touch screen monitor (10 points of contact)
and USB controller.
• Dimensions (width x height x depth)
- 558.40 × 349.80 × 121.41 mm.
- 21.98" × 13.77" × 4.78".
• Weight: 9.6 kg (21.1 lb)
• OSD (On Screen Display) menu; rear buttons.
System. • Processor: 4th Gen Intel® Core™ i3, 1.7 GHz, Dual Core.
• Memory: 8GB DDR3L, 1600 MHz.
• Graphics: Intel® HD Graphics 5000/4400.
• Storage (to choose):
- 16 GB SSD (approx. 7GB free for user).
- 16 GB + 128 GB SSD.
• OS Image: WES7P X64 MUI.
Regulation. • BSMI, CE, FCC, CCC, UL.
Ambient. • Storage temperature: -20 ~ 60 °C (-4 ~ 140 °F).
• Working temperature: 0 ~ 55 °C (32 ~ 101 °F).
• Relative humidity: 10 ~ 95% RH at 40°C (104°F) (non-condensing).
• Vibration: Vibration test, IEC 60068-2-6 compliant. Sine vibration at 1 g
amplitude between 5 ~ 500 Hz.
• Degree of protection: IP65 (at front), IP40 (at rear).
Power supply. The monitor and the panel PC must be powered separately.
• Supply voltage: 24 V DC ± 10 %, 5 A.
• Consumption: 55 W (typical), 100 W (max.).
Optionally, the monitor can be powered using a 12 V DC current via the DC jack
connector (consult with Fagor Automation).
Screen. • Type: TFT LED LCD FullHD.
• Screen: 10-point multi-touch capacitive.
• Size: 21.5" (aspect ratio 16:9).
• Screen color: 24 bits (16.7 million colors).
• Resolution: 1920 x 1080 pixels.
• Angle of vision: 178° (vertical), 178° (horizontal).
• Brightness: 300 cd/m².
• Contrast ratio: 5000:1 (typical).
• Lamp duration (MTBF): 50,000 hours.
Connectivity. Monitor.
• 1 USB touch controller, to be connected to the panel PC.
• 1 RS232 touch controller (non-functional).
• 1 VGA video input, to be connected to the panel PC.
• 1 DVI-D video input (non-functional).
Panel PC.
• 2 RS-232 (50 ~ 115.2 kbps) serial lines.
• 2 RS422/485 serial lines, automatic flow control, 50 ~ 115.2 kbps.
• 4 RJ45 LAN ports, 10/100/1000 Mbps, IEEE 802.3u
1000baseT, Fast Ethernet.
• 2 USB 2.0 ports (1 used by the monitor’s touch controller).
• 2 USB 3.0 ports
• 1 VGA output, 1920 × 1200 @ 60 Hz, 24 bpp.
• 1 HDMI output, 1.4a, 3200 x 2000 @ 60Hz, 24 bpp.
• 1 audio input.
• 1 audio output.
Both the touch controller and VGA connection for the monitor must be connected to the Fagor panel
PC. Always use the cables supplied by Fagor for the unit.
