Fagor 8065 M - 4.5 PPC-19 Voltage Supply; Monitor Power: 12 ~ 24 V DC

Panel PC.
CNC 8065
4.
·81·
(REF: 1801)
PPC-19.
4.5 Voltage supply for the module.
Monitor power: 12 ~ 24 V DC.
Power the monitor with a 12 ~ 24 V DC power supply.
Consumption.
• Consumption (12 V DC): 23 W (minimum); 43 W (maximum).
• Consumption (24 V DC): 23 W (minimum); 45 W (maximum).
Power supply.
Pin Signal. Function.
1 - - -.
2 V- 0 V reference signal.
3 V+ Power supply.
