Panel PC.
CNC 8065
3.
·58·
(REF: 1801)
PPC-21W.
Power button.
·RST· Reset button.
·Tx Rx· Transmission and reception LEDs.
·BTR· Battery status LED.
·HDD· Hard drive activity LED.
·PWR· Power status LED.
Button to turn the panel PC on and off.
Button to activate the hardware reset function.
Data transmission and reception LEDs on the COM ports.
Battery status LED. The LED is off when the battery is working
well and the LED turns on when the battery requires replacing.
Hard drive activity LED. The LED turns on when the hard drive
is active, otherwise the LED is turned off.
Power status LED. The LED turns on when the panel PC is
powered.
