Remote modules. RIO5, RIOW and RIOR series.
CNCelite
8058 8060
8065 8070
RIO5 REMOTE MODULES. (CANOPEN PROTOCOL).
3.
Power supply.
ꞏ37ꞏ
REF. 2107
Each input has 5 pins (RL, R+, R-, RF, SH). Use shielded cables connecting their meshes
to the corresponding shield pin.
4 wires.
R1+
R1-
RL1
RF1
R1+
R1-
RL1
RF1
R1+
R1-
RL1
RF1
3 wires. 2 wires.
