Remote modules. RIO5, RIOW and RIOR series.
CNCelite
8058 8060
8065 8070
RIOW REMOTE MODULES. (CANOPEN PROTOCOL).
4.
Installation of the modules.
ꞏ57ꞏ
REF. 2107
Side voltage jumpers.
Some modules, e.g. the digital inputs module, have some jumpers on the left side for
receiving and sending a current of 10 A needed to supply the module.
The jumpers of a module must latch into the grooves of the previous module. It must be borne
in mind that not all the modules have the same number of jumpers and grooves. Before
mounting a module with jumpers, make sure that the previous module has enough grooves
to receive the jumpers.
Cable connection.
Each connector only admits one cable. To insert several cables into one connector, join the
cables at a terminal and insert the terminal into the connector.
The cables are secured into the connectors by pressure. Insert a tool into the square hole
located on top of the connector, this opens the connector. Insert the cable into the connector
and remove the tool. After removing the tool, the cable stays fixed.
The voltage jumpers are sharp. Handle the modules carefully to prevent getting hurt.
DO NOT make any connection or connect any module or cable if the group is under power. Before
making any connection, disconnect the power supply cable of the leading (first) module (RIOW-
CANOPEN) and, if necessary, that of the power supply module (RIOW-PS24).
