Connecting the Pads and Pedals
Using the provided cables, connect each Trigger input jack on the rear panel of the module, and make sure each pad is
connected to its corresponding Trigger input jack.
Note:
1. The sound of the hi-hat depends on the hi-hat pedal. Just as with an acoustic drum set, the open hi-hat sounds when
the pedal is not depressed. When the pedal is depressed, the closed hi-hat sounds.
2. The touch surface of the cymbal pads (Ride, Crash, Hi-Hat) is close to the edge of the pad, unlike the rest of the pads.
Caution!
To prevent electric shock and damage to drum module or other devices, always turn off the power of
all devices before making any connections.
