Fastening the module
Bass drum and hi-hat pedal
1. Loosen the screw on the clamp.
2. Insert the drum module into the clamp.
3. Tighten the screw on the clamp.
Side arm (L1)
Loosen the wing screw.
Tighten the wing screw.
Install the Drum Module
1.
Place the Bassdrum Pad on the floor centered under the
rack. Then attach the Bassdrum Pedal to the Bassdrum
Pad.
2.
Place the Hi-Hat on the floor on the left side.
3.
Connect the clearly marked cables to the pads and
inputs of the module and you're ready to go!
Make the connections as follows.
To Next Page
