13 Motore1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATIONXEF 250 - Rev01 / 2020
14
2
1 11 143 4 6
12 10 9
8 13 5 7
1.7 VEHICLE COMPONENT LOCATION
Handlebar components
Ref. Component
1 High beam flashing button
2 Clutch lever
3 “SELECT” button
4 “ADJUST” button
5 Engine stop switch
6 Front brake lever
7 Throttle grip
8 Radiator cap
9 Fuel tank cap
10 Speedlight switch
11 Horn button
12 Low beam/high beam light switch
13 Starter switch
14 Dashboard
